6" Channel Equipment Tilt Model T6

Overcome what’s ahead of you by taking your productivity and versatility to the next level with the 6" Channel Equipment Tilt Trailer (T6), featuring an extra wide 83’’ (between the fenders) rear tilt deck.

Ready to haul low-profile equipment and more with its spacious deck, 11-degree tilt angle, multiple ways to secure cargo, and diamond plate knife edge, the T6 is packed with the features and options that someone has driven as you need when forging new paths. Built strong for the longest adventures, it’s a trailer that’s perfect for those who are passionate about what they do.

Deck Width: 83"
Deck Lengths: 16' to 24'
GVWR: 14,000 lbs
Load Capacity: 10,940 to 11,730 lbs

See PJ Trailers in stock Request a quote

Spec sheets & brochures

Spec Sheet PDF · 674 KB View Color Options PDF · 656 KB

Standard features

Feature	Standard	Available options
Axles	[72BT] (2) 7,000# Electric / Torsion	[92BT] (2) 7,000# w/14 Ply LR-G Tires Electric / Torsion
Suspension	Torsion Suspension	-
Tongue	6" Channel Tongue	-
Coupler	[J] BP 2-5/16" Adjustable (14,000 lb.)	[J] BP 2-5/16" Adjustable (14,000 lb.) [P] 3" Pintle Eye - Channel-Mount [T] BP 2-5/16" Adjustable Coupler (20,000 lb.) w/HD 6-Hole Channel Bracket
Safety Chains	5/16" Grade 70 Safety Chain w/Clevis hook (2 each)	-
Jack	Drop Leg Jack (10,000lb)	[-JA02] 2-Speed Gooseneck Jack Upgrade (12,000 lb.) [-JA05] 1 Hydraulic Jack (BP Only) [-JA06] 2 Hydraulic Jacks (GN Upgrade) [-JA15] Upgrade to Dual 10k Jacks [-JA17] Single 2-speed Jack (12,000 lb.) (BP Only) [-JA18] Dual 2-Speed Jacks (BP Only) [-JA19] 2 Hydraulic Jacks for BP
Frame	6" Channel Frame	[-CM12] 12" OC Crossmembers
Cross-Members	3” Channel Crossmembers 16” oc	-
Floor	2" Treated Pine Lumber Deck	[-BWOD] Blackwood Pro Outer Deck [-BWFD] Blackwood Pro Full Deck (Excluding Tail) [-FLRO] Rough Oak Floor [-FLNF] No Flooring [-SF01] 11ga (1/8") DP Steel Floor w/ Flushmount D-Rings & 12" OC [-SF04] 3/16" DP Steel Floor w/ Flushmount D-Rings & 12" OC
Fenders	9" x 72" Treadplate Removable Steel Fenders	[-FE01] 1/4" DP HD Weld on Fenders Tandem Axle [-FE02] 1/4" DP HD Weld on Fenders Triple Axle [-FE04] Weld on Fenders
Stake Pockets	24" Stake Pocket Spacing	[-2SPF] 2 Stake Pockets In Front of Trailer
Lights	Available as an option	[-LT10] GN Light Bar w/ 4 Lights (GN Only)
Wiring	All-Weather Wiring Harness (7-way RV)	-
Tires	ST235/80R16 Radial Tires 10 ply (3,520 lbs.)	-
Paint Color	[K] Primer + Black Powder Coat	[1] Primer + Red Powder Coat [3] Primer + White Powder Coat [5] Primer + Tractor Orange Powder Coat [6] Primer + Grey Powder Coat [8] Primer + Desert Tan Powder Coat [B] Primer + Jet Blue Coat (NEW!) [J] Primer + Industrial Green Coat (NEW!) [Y] Primer + Industrial Yellow Coat (NEW!) [G] Primer + Slime Green Coat (NEW!)
Tilt Deck Dimensions	74" Wide Tiltable Deck	-
Rubrail	Rubrail & Stake Pockets	-
Tie-Downs	(6) Flushmount D-rings	[-DR01] 1 Extra Pair D-Rings [-DR21] 1 Extra Pair Flushmount D-Rings
Battery	Available as an option	[-BYSL] Solar Battery Charger
Hydraulics	Available as an option	[-PUGD] Power Up/Down & Gravity Down Upgrade
Storage	Available as an option	[-GNC2] 2 GN Lockable Chain Holders [-GNCH] GN Lockable Chain Holder [-TB02] Top Riser Toolbox [-TB03] Full Size Divided Toolbox Upgrade [-TB05] Front Toolbox [-TB06] Locking Lid Over Tongue
Cargo Winch	Available as an option	[-WN01] Plate for Winch (BP Only) [-WN02] HD GN Winch Plate [-WN03] Winch Plate w/ Welded Receiver Hitch [-WN04] Gooseneck Winch Plate [-WN12] Winch 12.5K w/Plate & Battery [-WN18] Winch 18K w/HD Plate & Battery [-WN95] Winch 10k w/ Plate & Battery [-WNFR] Roller on Front of Deck for Winch Cable
Pipe Chain Spools	Pipe Spools	-
Tilt Deck Angle	11°	-
Tail	[T] 16' Tilt Deck	-
Other Options	Available as an option	[-FR01] Fork Rack [-GV09] 9,900 G.V.W.R. [-GV16] 16,000 GVWR Must have 16k coupler/7k axles min. [-TRA1] 1/2 x 1/2 Square Traction Bars

Models & dimensions

Model	Pull Type	GVWR	Empty Weight	Deck Length	Deck Width	Tongue Length
T6 (16')	Bumperpull	14000 lbs	3060 lbs	16	83"	5' 1" (61")
T6 (18')	Bumperpull	14000 lbs	3240 lbs	18	83"	5' 1" (61")
T6 (20')	Bumperpull	14000 lbs	3420 lbs	20	83"	5' 1" (61")
T6 (22')	Bumperpull	14000 lbs	3710 lbs	22	83"	5' 1" (61")
T6 (24')	Bumperpull	14000 lbs	3950 lbs	24	83"	5' 1" (61")
