PJ Trailers

83" Pro-Lift Dump Model DT

Does getting a job done, especially big ones that are difficult and challenging, drive you? Then the 83" Pro-Lift Dump (DT) is for you

For professionals in construction, landscaping, and even waste management, the DT is engineered and designed to haul and transport heavy-duty, bulky cargo and debris. And it gets the job done with its first-rate 12-ton front-mounted telescopic cylinder and adaptable 2-way gate system, making unloading and loading an easy task instead of a back-breaking one. We know you’re driven; it’s time to get a trailer that has the same drive as you.

Deck Width: 83"
Deck Lengths: 14' to 16'
GVWR: 14,000 lbs
Load Capacity: 9,750 to 11,920 lbs

See PJ Trailers in stock Request a quote

Spec sheets & brochures

Spec Sheet PDF · 860 KB View Color Options PDF · 656 KB

Standard features

Feature	Standard	Available options
Axles	[72BS] (2) 7,000# Electric / Spring	[72BD] (2) 7,000# Electric / Drop Axle [82BS] (2) 8,000# Oil Bath w/14 Ply LR-G Tires Electric / Spring [92BS] (2) 7,000# w/14 Ply LR-G Tires Electric / Spring [92BD] (2) 7,000# w/14 Ply LR-G Tires Electric / Drop Axle [K2BS] (2) 8,000# Oil Bath w/215/75R17.5 LR-H Singles Electric / Spring [Y2BS] (2) 7,000# w/215/75R17.5 LR-H Singles Electric / Spring
Suspension	6-Leaf Slipper Spring Suspension	-
Tongue	8" x 13 lb. I-beam Tongue	-
Coupler	[J] BP 2-5/16" Adjustable- Demco EZ-Latch	[A] BP 2-5/16" Adjustable (14,000 lb.) [P] 3" Pintle Eye - Channel-Mount (20,000 lb.) [T] BP 2-5/16" Adjustable Coupler (20,000 lb.) w/HD 6-Hole Channel Bracket
Jack	Drop Leg Jack (12,000 lb.)	[-JA02] 2-Speed Gooseneck Jack Upgrade (12,000 lb.) [-JA04] Upgrade to Single 10k Jack (BP Only) [-JA17] Single 2-speed Jack (12,000 lb.) (BP Only)
Frame	8" x 13 lb. I-Beam Main Frame	[-CM12] 12" OC Crossmembers
Cross-Members	3" Channel Crossmembers on 16" Centers	-
Floor	7ga. Steel Bed	[-SF06] 7ga Smooth Plate Steel Floor w/ 4 D-Rings
Fenders	1/8" Treadplate Steel Fenders	-
Ramps	6' 6" Slide-In Channel Ramps	-
Stake Pockets	Stake Pockets along both sides (Quantity depends on length)	-
Wiring	All-Weather Wiring Harness (7-way RV)	-
Tires	ST235/80R16 Radial Tires 10 ply (3,520 lbs.)	-
Paint Color	[K] Black Powder Coat	[K] Black Powder Coat [0] Primer + Black Powder Coat (Texas Only) [1] Primer + Red Powder Coat (Texas Only) [3] Primer + White Powder Coat (Texas Only) [5] Primer + Tractor Orange Powder Coat (Texas Only) [6] Primer + Grey Powder Coat (Texas Only) [8] Primer + Desert Tan Powder Coat (Texas Only) [P] Primer Only [Z] No Paint No Primer
Tie-Downs	(4) D-Rings (Welded inside the Box)	[-DR01] 1 Extra Pair D-Rings
Breakaway System	Electric Breakaway System w/ Charger	-
Battery	12V Deep Cycle Battery	[-BYEB] 1 Extra Battery [-BYSC] Solar Battery Charger
Charging System	110V Integrated Trickle Charger	-
Hydraulics	Hydraulic - Power Up / Gravity Down	-
Lift Type	3-Stage Telescopic Cylinder	-
Sides	24" 10ga. UniWall Steel Sides	[-SE24] 24" Side Extensions (Solid) [-SW03] 3ft Tall Sides [-SW04] 4ft Tall Sides
Steps	Treadplate Step (Both Sides)	-
Storage	Available as an option	[-TB02] Top Riser Toolbox
Tarp	Roll-up Tarp Kit (Pull Bar) 7' x 20'	-
Cargo Winch	Available as an option	[-WN01] Plate for Winch (BP Only) [-WN02] HD GN Winch Plate [-WN04] Gooseneck Winch Plate [-WN12] Winch 12K w/Plate & Battery
Tail	[T] Split / Spreader Gate	-
Dump Gate	2-Way Gate (Barn Doors & Spreader Gate)	-
Lift Cylinder	120" Cylinder on 14' length & 144" Cylinder on 16' length	-
Other Options	Available as an option	[-DON1] Removable Deck on the Neck (102" Wide 96" Long) [-GV09] 9,900 G.V.W.R. [-GV16] 16,000 GVWR Must have 16k coupler/7k axles min. [-RS01] Rear Support Stands
