8" I-Beam Deckover Model F8

Step up to the 8" I-Beam Deckover Trailer (F8), a big and strong hauler with a pintle hitch that’s born to take on heavy-duty towing jobs.

From sun up to sun down, 24/7, the F8 overcomes challenging conditions and obstacles with its low-profile bed, lifetime LED lighting, and powerful I-beam frame. Available with up to a 16,000 lbs G.V.W.R., it’s purpose-built to haul big loads and heavy equipment in agricultural, construction, and landscaping applications. You work hard for your dreams; isn’t it time to get a trailer that does the same?

Deck Width: 102"
Deck Lengths: 16' to 30'
GVWR: 14,000 lbs
Load Capacity: 6,770 to 11,400 lbs

See PJ Trailers in stock Request a quote

Spec sheets & brochures

Spec Sheet PDF · 1,017 KB View Color Options PDF · 656 KB

Standard features

Feature	Standard	Available options
Axles	[72BS] (2) 7,000# Electric / Spring	[82BS] (2) 8,000# Oil Bath w/14 Ply LR-G Tires Electric / Spring [92BS] (2) 7,000# w/14 Ply LR-G Tires Electric / Spring [B2BS] (2) 8,000# Oil Bath Axles, 235/80 LR-E Tires Electric / Spring [K2BS] (2) 8,000# Oil Bath w/215/75R17.5 LR-H Singles Electric / Spring
Suspension	6-Leaf Slipper Spring Suspension	-
Tongue	8" I-beam Tongue	-
Coupler	[J] BP 2-5/16" Adjustable (14,000 lb.)	[J] BP 2-5/16" Adjustable (14,000 lb.) [P] 3" Pintle Eye - Channel-Mount (20,000 lb.) [T] BP 2-5/16" Adjustable Coupler (20,000 lb.) w/HD 6-Hole Channel Bracket
Safety Chains	5/16" Grade 70 Safety Chain w/Clevis hook (2 each)	-
Jack	Drop Leg Jack (10,000lb)	[-JA04] Upgrade to Single 10k Jack (BP Only) [-JA05] 1 Hydraulic Jack (BP Only) [-JA08] Dual 10k Jacks at Rear of Deck [-JA17] Single 2-speed Jack (12,000 lb.) (BP Only) [-JA18] Dual 2-Speed Jacks (BP Only) [-JA19] 2 Hydraulic Jacks for BP [-JA21] Dual Jacks for BP
Frame	8" x 10 lb. I-Beam Main Frame	[-CM12] 12" OC Crossmembers
Cross-Members	3" Channel Crossmembers on 16" Centers	-
Bump Rail	Front Bump Rail	-
Floor	2" Treated Pine Lumber Deck	[-BWFT] Blackwood Pro Full Deck (Tail Only) [-FLWD] Add Wood to Dovetail [-BWOD] Blackwood Pro Outer Deck [-BWFD] Blackwood Pro Full Deck [-FLRO] Rough Oak Floor [-FLNF] No Flooring [-SF01] 11ga (1/8") DP Steel Floor w/ Flushmount D-Rings & 12" OC [-SF04] 3/16" DP Steel Floor w/ Flushmount D-Rings & 12" OC
Ramps	6' 6" Slide-In Channel Ramps	[-NRNP] No Ramps No Ramp Pockets
Stake Pockets	Stake Pockets along both sides (Quantity depends on length)	[-2SPF] 2 Stake Pockets In Front of Trailer
Lights	Available as an option	[-LT10] GN Light Bar w/ 4 Lights (GN Only)
Wiring	All-Weather Wiring Harness (7-way RV)	-
Tires	ST235/80R16 Radial Tires 10 ply (3,520 lbs.)	-
Paint Color	[K] Primer + Black Powder Coat	[K] Black Powder Coat [0] Primer + Black Powder Coat (Texas Only) [1] Primer + Red Powder Coat (Texas Only) [3] Primer + White Powder Coat (Texas Only) [5] Primer + Tractor Orange Powder Coat (Texas Only) [6] Primer + Grey Powder Coat (Texas Only) [8] Primer + Desert Tan Powder Coat (Texas Only) [P] Primer Only [Z] No Paint No Primer
Rubrail	2" Rubrail	-
Tie-Downs	Available as an option	[-RT01] 1 Pair Weld-On Ratchets [-RTST] 4" Ratchets every 4ft w/ Slide Track [-2RST] 4" Ratchets every 4ft w/ Slide Track (BOTH SIDES) [-UFTD] Under Frame Tie Down Flat [-UFT2] Under Frame Tie Down Flat on Both Sides [-DR01] 1 Extra Pair D-Rings [-DR21] 1 Extra Pair Flushmount D-Rings
Breakaway System	Electric Breakaway Kit w/ Charger	-
Battery	Available as an option	[-BYSC] Solar Battery Charger
Storage	Tool Tray in Tongue	[-SB01] 1 Side-mount Toolbox 30"x14" [-SB02] 1 Side-mount Toolbox 45"x14" [-SB03] 1 Side-mount Toolbox 72"x14" [-TB03] Full Size Divided Toolbox Upgrade [-TB04] Full Size Toolbox (Bumper Pull) [-TB05] Front Toolbox [-TB06] Locking Lid Over Tongue
Cargo Winch	Available as an option	[-WN01] Plate for Winch (BP Only) [-WN02] HD GN Winch Plate [-WN03] Winch Plate w/ Welded Receiver Hitch [-WN12] Winch 12.5K w/Plate & Battery [-WN18] Winch 18K w/HD Plate & Battery [-WN95] Winch 10k w/ Plate & Battery [-WNFR] Roller on Front of Deck for Winch Cable [-WNRR] Roller on Rear of Deck for Winch Cable
Tail	[S] Straight Deck w/ 6'6" Slide-in Ramps	[A] 3' Dovetail w/ 5' Slide-in Ramps (18' and up) [B] 3' Dovetail w/ 2, 16" x 60" Foldup Ramps [D] 3' Dovetail w/ 2, 31" x 66" HD Foldup Ramps [P] 4' Dove with 2 Flipover Ramps (20' and up) [Y] 4' Dove with 4' Monster Ramps (20' and up)
Other Options	Available as an option	[-GV09] 9,900 G.V.W.R. [-GV16] 16,000 GVWR Must have 16k coupler/7k axles min. [-MF01] Mud Flaps Single Wheel Deckover [-RASA] Ramp Support Arms [-RS01] Rear Support Stands

Models & dimensions

Model	Pull Type	GVWR	Empty Weight	Payload Capacity	Deck Length	Deck Width	Tongue Length
F8 (16')	Bumperpull	14000 lbs	3130 lbs	10870 lbs	16	102"	6' 3" (75")
F8 (18')	Bumperpull	14000 lbs	3340 lbs	10660 lbs	18	102"	6' 3" (75")
F8 (20')	Bumperpull	14000 lbs	3550 lbs	10450 lbs	20	102"	6' 3" (75")
F8 (22')	Bumperpull	14000 lbs	3760 lbs	10240 lbs	22	102"	6' 3" (75")
F8 (24')	Bumperpull	14000 lbs	3970 lbs	10030 lbs	24	102"	6' 3" (75")
F8 (26')	Bumperpull	14000 lbs	4180 lbs	9820 lbs	26	102"	6' 3" (75")
F8 (28')	Bumperpull	14000 lbs	4390 lbs	9610 lbs	28	102"	6' 3" (75")
F8 (30')	Bumperpull	14000 lbs	4600 lbs	9400 lbs	30	102"	6' 3" (75")
