PJ Trailers · Deckovers
6" Channel Deckover Model L7
Proven PJ Quality. Exceptional Value.
The L7 deckover trailer is built for professionals with a durable 6-inch channel frame and tongue. It offers a 102" wide deck, 35" deck height, full-length rubrail, and stake pockets for secure hauling. Standard slide-in ramps and 7K axles with forward self-adjusting brakes ensure reliability, while the 7000 lb. drop-leg jack adds stability during setup.
- Deck Width
- 101"
- Deck Lengths
- 18' to 22'
- GVWR
- 14,000 lbs
- Load Capacity
- 10,400 to 10,840 lbs
Spec sheets & brochures
Standard features
| Feature | Standard | Available options |
|---|---|---|
| Axles | [72BS] (2) 7,000# Electric / Spring |
|
| Suspension | 6-Leaf Slipper Spring Suspension | - |
| Tongue | 6" Channel Tongue | - |
| Coupler | [C] BP 2-5/16" Adjustable |
|
| Safety Chains | 5/16" Grade 70 Safety Chain w/Clevis hook (2 each) | - |
| Jack | 7,000# Top Wind Drop Leg Jack | - |
| Frame | 6" Channel Frame | - |
| Cross-Members | 3" Channel Crossmembers on 16" Centers | - |
| Bump Rail | Tube Frame Headboard | - |
| Floor | 2" Treated Pine Lumber Deck | - |
| Ramps | 8' Slide in Ramps w/ Holders w/ integrated Ramp Door | - |
| Stake Pockets | Stake Pockets along both sides (Quantity depends on length) | - |
| Wiring | All-Weather Wiring Harness (7-way RV) | - |
| Tires | ST235/80R16 Radial Tires 10 ply (3,520 lbs.) | - |
| Spare Mount | Front Spare Tire Mount | - |
| Spare Tire | Available as an option |
|
| Paint Color | [K] Primer + Black Powder Coat |
|
| Breakaway System | Electric Breakaway System w/ Charger | - |
| Other Options | Available as an option |
|
Models & dimensions
| Model | Pull Type | GVWR | Empty Weight | Payload Capacity | Deck Length | Deck Width | Tongue Length |
|---|---|---|---|---|---|---|---|
| L7 (18') | Bumperpull | 14000 lbs | 3160 lbs | 10840 lbs | 18 | 101" | 63-1/4" |
| L7 (20') | Bumperpull | 14000 lbs | 3360 lbs | 10640 lbs | 20 | 101" | 63-1/4" |
| L7 (22') | Bumperpull | 14000 lbs | 3600 lbs | 10400 lbs | 22 | 101" | 63-1/4" |
We carry PJ Trailers
Want this PJ Trailers 6" Channel Deckover (L7)? Check what we have on the lot right now, or ask us to order the exact configuration you need.
