PJ Trailers · Dump Trailers

HD Low-Pro Dump Model DE

The road ahead may have its share of obstacles, but challenges don’t have to slow you down or stop you from chasing your dreams. You can haul, load, and unload it all with a dump trailer that works as hard as you do: the HD Low-Pro Dump Trailer (DE).

The DE gives you stability, security, and strength with tandem torsion axles and super single wheels, built to handle heavy-duty hauls and hefty loads with confidence. With a 20,000 lbs G.V.W.R., it is no lightweight. This trailer means business. We designed it around the real-world demands of people hauling in the toughest industries and environments, so you get a trailer that is up for anything.

Bed Width: 82.5"
Bed Lengths: 16' to 16'
GVWR: 21,000 lbs
Load Capacity: 13,400 lbs

See PJ Trailers in stock Request a quote

Spec sheets & brochures

Spec Sheet PDF · 905 KB View Color Options PDF · 656 KB

Standard features

Feature	Standard	Available options
Axles	[S2BT] (2) 10,000# w/235/75R17.5" LR-J Single T&W Electric / Torsion	[S2BT] (2) 10,000# w/235/75R17.5" LR-J Single T&W Electric / Torsion
Suspension	Torsion Suspension	-
Tongue	10" x 19 lb. I-beam Tongue	-
Coupler	Available as an option	[R] GN 2-5/16" Round (25,000 lb.)
Jack	Spring Loaded Drop Leg Jack (12,000 lb.)	[-JA01] Dual HD 25k Jost Jacks [-JA02] 2-Speed Gooseneck Jack Upgrade (12,000 lb.) [-JA04] Upgrade to Single 10k Jack (BP Only) [-JA05] 1 Hydraulic Jack (BP Only) [-JA06] 2 Hydraulic Jacks (GN Upgrade) [-JA17] Single 2-speed Jack (12,000 lb.) (BP Only) [-JA21] Dual Jacks for BP
Frame	10" x 19 lb. I-Beam Main Frame	[-CM12] 12" OC Crossmembers
Cross-Members	3" Channel Crossmembers on 16" Centers	-
Floor	7ga. Steel Bed	-
Fenders	1/8" Treadplate Steel Fenders	-
Ramps	6' 6" Slide-In Channel Ramps	-
Stake Pockets	Stake Pockets along both sides (Quantity depends on length)	-
Wiring	All-Weather Wiring Harness (7-way RV)	-
Tires	ST235/75/R17.5 Radial Tires 18 ply (6,005 lbs.)	-
Paint Color	[K] Primer + Black Powder Coat	[1] Primer + Red Powder Coat (Texas Only) [3] Primer + White Powder Coat (Texas Only) [5] Primer + Tractor Orange Powder Coat (Texas Only) [6] Primer + Grey Powder Coat (Texas Only) [8] Primer + Desert Tan Powder Coat (Texas Only) [B] Primer + Jet Blue Coat (NEW!) (Texas Only) [J] Primer + Industrial Green Coat (NEW!) (Texas Only) [Y] Primer + Industrial Yellow Coat (NEW!) (Texas Only) [G] Primer + Slime Green Coat (NEW!) (Texas Only)
Tie-Downs	(4) D-Rings (Welded inside the Box)	[-DR01] 1 Extra Pair D-Rings
Breakaway System	Electric Breakaway System w/ Charger	-
Battery	12V Deep Cycle Battery	[-BYEB] 1 Extra Battery [-BYSC] Solar Battery Charger
Charging System	110V Integrated Trickle Charger	-
Hydraulics	Hydraulic - Power Up/Power Down & Gravity Down	-
Lift Type	Scissor Lift	-
Sides	36" 7 ga. UniWall Steel Sides	[-SE24] 24" Side Extensions (Solid) [-SW04] 4ft Tall Sides
Storage	Available as an option	[-TB02] Top Riser Toolbox
Tarp	Roll-up Tarp Kit (Pull Bar) 7' x 20'	-
Cargo Winch	Available as an option	[-WN01] Plate for Winch (BP Only) [-WN02] HD GN Winch Plate [-WN04] Gooseneck Winch Plate
Tail	[T] Split / Spreader Gate	-
Dump Gate	2-Way Gate (Barn Doors & Spreader Gate)	-
Lift Cylinder	6" x 21" Cylinder w/Scissor	-
Other Options	Available as an option	[-DON1] Removable Deck on the Neck (102" Wide 96" Long) [-RS01] Rear Support Stands
