Low-Pro Flatdeck With Duals Model LD

Need more strength? Then it’s time for the Low-Pro Flatdeck With Duals Trailer (LD).

This powerful gooseneck trailer helps you take on the toughest jobs, even in rough terrain. With 10K axles and forward self-adjusting brakes, plus a heavy-duty adjustable suspension, the LD is built to give you long-lasting strength and durability. Whether you're hauling heavy equipment or vehicles, it's ready to help you get the job done and achieve your goals.

Deck Width: 102"
Deck Lengths: 20' to 44'
GVWR: 25,000 lbs
Load Capacity: 16,770 to 19,370 lbs

See PJ Trailers in stock Request a quote

Spec sheets & brochures

Spec Sheet PDF · 784 KB View Color Options PDF · 656 KB

Standard features

Feature	Standard	Available options
Axles	[A2BS] (2) 10,000# Axles Electric / Spring	[C2BS] (2) 12,000# Axles Electric / Spring [C2HA] (2) 12,000# Axles Elec/Hyd Disc (1,600 PSI Pump) / Air Ride [C2HS] (2) 12,000# Axles Elec/Hyd Disc (1,600 PSI Pump) / Spring [D2BS] (2) 12,000# w/14 Ply LR-G Dual T&W Electric / Spring [D2HS] (2) 12,000# w/14 Ply LR-G Dual T&W Elec/Hyd Disc (1,600 PSI Pump) / Spring [J2GS] (2) 15,000# w/215/75R17.5" LR-H Dual T&W Elec/Hyd Drum (1,000 PSI Pump) / Spring [N2HA] (2) 12,000# w/215/75R17.5" LR-H Dual T&W Elec/Hyd Disc (1,600 PSI Pump) / Air Ride [S2BS] (2) 10,000# w/235/75R17.5" LR-J Single T&W Electric / Spring [S2HS] (2) 10,000# w/235/75R17.5" LR-J Single T&W Elec/Hyd Disc (1,600 PSI Pump) / Spring [T2BS] (2) 10,000# w/14 Ply LR-G Dual T&W Electric / Spring [T2HS] (2) 10,000# w/14 Ply LR-G Dual T&W Elec/Hyd Disc (1,600 PSI Pump) / Spring
Suspension	HDSS Adjustable Suspension	-
Tongue	12" x 19 lb. I-beam Tongue (ProBeam™)	-
Coupler	[Q] GN 2-5/16" Square Demco EZ Latch (30,000 lb.) w/ Toolbox	[Q] GN 2-5/16" Square Demco EZ Latch (30,000 lb.) w/ Toolbox
Safety Chains	3/8" Grade 70 Safety Chain w/Clevis hook (2 each)	-
Jack	(2) Drop Leg Jacks (10,000 lb.)	[-JA01] Dual HD 25k Jost Jacks [-JA02] 2-Speed Gooseneck Jack Upgrade (12,000 lb.) [-JA06] 2 Hydraulic Jacks (GN Upgrade) [-JA08] Dual 10k Jacks at Rear of Deck [-JA14] 2 Hydraulic Jacks (w/single pump & diverter)
Frame	12" x 19 lb. I-Beam Main Frame\|TwistGuard™ standard on 30' and up	[-FR22] 22 lb. I-Beam Main Frame [-CM12] 12" OC Crossmembers [-FRFB] Frame Bridging [-FRTG] TwistGuard™ (Under 30')
Cross-Members	3” Channel Crossmembers 16” oc	-
Floor	2" Treated Pine Lumber Deck	[-BWFT] Blackwood Pro Tail (Excluding Deck) [-FLWD] Add Wood to Dovetail [-BWOD] Blackwood Pro Outer Deck [-BWFD] Blackwood Pro Full Deck (Excluding Tail) [-FLRO] Rough Oak Floor [-FLNF] No Flooring [-SF01] 11ga (1/8") DP Steel Floor w/ Flushmount D-Rings & 12" OC [-SF04] 3/16" DP Steel Floor w/ Flushmount D-Rings & 12" OC [-SF05] ¼" DP Steel Floor w/ Flushmount D-Rings & 12" OC
Fenders	Diamond Plate Low-Pro Fenders	-
Ramps	8' Slide-In Channel Ramps	[-NRNP] No Ramps No Ramp Pockets
Stake Pockets	24" Stake Pocket Spacing	-
Lights	Available as an option	[-LT10] GN Light Bar w/ 4 Lights (GN Only) [-SL02] 2 Extra Side Marker 3/4" Bullet Lights, 1 Per Side [-LT11] Auxiliary Work Light Package (GN Only)
Wiring	All-Weather Wiring Harness (7-way RV)	-
Tires	ST235/80R16 Radial Tires 10 ply (3,080 lbs.)	-
Paint Color	[K] Primer + Black Powder Coat	[0] Primer + Black Powder Coat [1] Primer + Red Powder Coat [3] Primer + White Powder Coat [5] Primer + Tractor Orange Powder Coat [6] Primer + Grey Powder Coat [8] Primer + Desert Tan Powder Coat [B] Primer + Jet Blue Coat (NEW!) [J] Primer + Industrial Green Coat (NEW!) [Y] Primer + Industrial Yellow Coat (NEW!)
Rubrail	Rubrail & Stake Pockets	-
Tie-Downs	Available as an option	[-RT01] 1 Pair Weld-On Ratchets [-RTST] 4" Ratchets every 4ft w/ Slide Track [-2RST] 4" Ratchets every 4ft w/ Slide Track (BOTH SIDES) [-UFTD] Under Frame Tie Down Flat [-UFT2] Under Frame Tie Down Flat on Both Sides [-DR01] 1 Extra Pair D-Rings [-DR21] 1 Extra Pair Flushmount D-Rings
Breakaway System	Electric Breakaway Kit w/ Charger	-
Battery	Available as an option	[-BYEB] 1 Extra Battery [-BYBC] 1 Extra Battery Charger 12V [-BYSL] Solar Battery Charger
Steps	Retractable Monster Step on Both Sides	-
Storage	Available as an option	[-DA02] 2 Daikin toolboxes [-GNCH] GN Lockable Chain Holder [-SB02] 1 Side-mount Toolbox 45" x 14" [-SB03] 1 Side-mount Toolbox 72" x 14" [-TB02] Top Riser Toolbox
Cargo Winch	Available as an option	[-WN02] HD GN Winch Plate [-WN03] Winch Plate w/ Welded Receiver Hitch [-WN04] Gooseneck Winch Plate [-WN12] Winch 12.5K w/Plate & Battery [-WN18] Winch 18K w/HD Plate & Battery [-WN95] Winch 10k w/ Plate & Battery [-WNRR] Roller on Rear of Deck for Winch Cable
Pipe Chain Spools	Pipe Spools	-
Twist Guard™	TwistGuard™ Standard on 30' and Up	-
Tail	[S] Straight Deck w/ 2 Slide-in Ramps	[F] 5' Dovetail w/ 2 Flip-over Ramps [W] 5' Dovetail w/ 2 Flip-over Monster Ramps [Z] 5' Dovetail w/ Power Tail (Pat. Pend. TX Only)
Other Options	Available as an option	[-DON1] Removable Deck on the Neck (102" Wide 96" Long) [-DON3] Rem Deck on Neck w/SlideTrk & 2 Ratchets(102"x96") [-GV25] 25,900 GVWR Must Select 12K Axles [-GV30] 30,000 GVWR Must have 30k coupler/12k axles or higher [-RASA] Ramp Support Arms [-RAWR] Hinged Side Mount Wood Rack

Models & dimensions

Model	Pull Type	GVWR	Empty Weight	Payload Capacity	Deck Length	Deck Width
LD (20')	Gooseneck	25000 lbs	5630 lbs	19370 lbs	20	102"
LD (22')	Gooseneck	25000 lbs	5890 lbs	19110 lbs	22	102"
LD (24')	Gooseneck	25000 lbs	6130 lbs	18870 lbs	24	102"
LD (26')	Gooseneck	25000 lbs	6410 lbs	18590 lbs	26	102"
LD (28')	Gooseneck	25000 lbs	6670 lbs	18330 lbs	28	102"
LD (30')	Gooseneck	25000 lbs	6930 lbs	18070 lbs	30	102"
LD (32')	Gooseneck	25000 lbs	7190 lbs	17810 lbs	32	102"
LD (34')	Gooseneck	25000 lbs	7450 lbs	17550 lbs	34	102"
LD (36')	Gooseneck	25000 lbs	7710 lbs	17290 lbs	36	102"
LD (38')	Gooseneck	25000 lbs	7970 lbs	17030 lbs	38	102"
LD (40')	Gooseneck	25000 lbs	8230 lbs	16770 lbs	40	102"
LD (42')	Gooseneck	25000 lbs	8490 lbs	16510 lbs	42	102"
LD (44')	Gooseneck	25000 lbs	8750 lbs	16250 lbs	44	102"
